StewMac Stingray-style Bass Bridge

StewMac Stingray-style Bass Bridge

A classic round-plate design with flexible string loading

The round-plate bridge has defined the StingRay look since 1976. Four adjustable barrel saddles span the face of the plate, allowing you to control each string's height and intonation.

Strings can be installed through the body or loaded from the top, letting you choose between the steeper break angle of a through-body and the reduced angle of a top-loader. Either way, you get the same classic round-plate design with the adjustment you need for a proper setup.

Specifications:

• String Spacing: 3/4" / 0.760" / 19.30mm
• String Spread: 2-9/32" / 2.280" / 57.90mm
• Mounting Screw Spread (3 Screw): 1-17/32" / 1.520" / 38.6mm
• Mounting Screw Spread (2 Screw): 3-21/32" / 3.661" / 93.00mm
• Overall Width: 4-1/8" / 4.134" / 105.00mm
• Overall Height: 3-9/32" / 3.268" / 83.00mm
• Bridge Height: 23/32" / 0.709" / 18.00mm

Features:

• Material: Steel plate and saddles
• Mount: 5-screw
• Stringing: Through-body or top-load
• Includes: 5 mounting screws
